Product Summary
The OPA2348AIDR is a single supply, low-power, CMOS op amp in micro packaging. Featuring an extended bandwidth of 1MHz, and a supply current of 45μA, it is useful for low-power applications on single supplies of 2.1V to 5.5V. Low supply current of 45μA, and an input bias current of 0.5pA, make the OPA2348AIDR an optimal candidate for low-power, high-impedance applications such as smoke detectors and other sensors. The applications of the OPA2348AIDR include portable equipment, battery-powered equipment, smoke alarms, co detectors and medical instrumentation.
Parametrics
OPA2348AIDR absolute maximum ratings: (1)Supply Voltage: V– to V+ 7.5V; (2)Signal Input Terminals, Voltage: (V–) – 0.5V to (V+) + 0.5V; Current: 10mA; (3)Output Short-Circuit: Continuous; (4)Operating Temperature: –65 to +150℃; (5)Storage Temperature: –65 to +150℃; (6)Junction Temperature: 150℃; (7)Lead Temperature (soldering, 10s): 300℃.
Features
OPA2348AIDR features: (1)low IQ: 45μA typical; (2)low cost; (3)rail-to-rail input and output; (4)single supply: +2.1V to +5.5V; (5)input bias current: 0.5pA; (6)microsize packages: SC70-5, SOT23-8 and TSSOP-14; (7)high speed:power with bandwidth: 1MHz.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 OPA2348AIDR |
Texas Instruments |
Operational Amplifiers - Op Amps 1MHz 45uA RRIO Dual Op Amp |
Data Sheet |
|
|
||||||||||||
|
OPA2348AIDRG4 |
Texas Instruments |
Operational Amplifiers - Op Amps 1MHz 45uA RRIO Dual Op Amp |
Data Sheet |
|
|
||||||||||||
